| Operating voltage KNX | <10 mA |
| Installation type | DIN rail |
| Width | 4 modules |
| Type of connection | Terminal screws | Bus connection: KNX bus terminal |
| Max. cable cross section | Solid wire: 0.5 mm² (Ø 0.8) to 4 mm² | Stranded wire with end sleeve: 0.5 mm² to 2.5 mm² |
| Number of channels | 4 |
| Type of contact | 25 A, 16 A |
| Opening width | < 3 mm |
| Resistive load | 4800 W |
| Energy saving lamps | 410 W |
| LED lamp < 2 W | 75 W |
| LED lamp 2-8 W | 850 W |
| LED lamp > 8 W | 850 W |
| Inrush current | max. 1200 A / 200 µs |
| Switching of various phases | Possible |
|
| Type | Module FIX1 |
| Ambient temperature | -5°C ... 45°C |
| Type of protection | IP 20 |
| Protection class | II according to EN 60 669 |
