| Operating voltage KNX |
Bus voltage, ≤4 mA |
| Operating voltage |
230 V AC |
| Frequency |
50 Hz |
| Width |
4 modules |
| Installation type |
DIN rail |
| Type of connection |
Terminal screws | Bus connection: KNX bus terminal |
| Max. cable cross section |
Solid wire: 0.5 mm² (Ø 0.8) to 4 mm² | Stranded wire with end sleeve: 0.5 mm² to 2.5 mm² |
| Number of channels |
2 |
| Lamp types |
Incandescent, low-voltage and high-voltage halogen and dimmable energy saving lamps and LED |
| Switching capacity per channel |
400 W |
| Switching capacity in parallel operation |
800 W |
| LED lamp |
Trailing edge (RC-mode): 400 W |
| Energy saving lamps |
Trailing edge (RC-mode): 400 W |
| Switching capacity min. |
5 W |
| Max. cable length |
100 m |
| Ambient temperature |
-5 °C … +45 °C |
| Type of protection |
IP 20 |
| Protection class |
II according to EN 60 669 |
