| Operating voltage KNX |
Bus voltage, <4 mA |
| Operating voltage |
110 – 240 V AC |
| Frequency |
50 – 60 Hz |
| Stand-by consumption |
~0,5 W |
| Installation type |
DIN rail |
| Width |
8 modules |
| Type of connection |
Terminal screws | Bus connection: KNX bus terminal |
| Max. cable cross section |
Solid wire: 0.5 mm² (Ø 0.8) to 4 mm² | Stranded wire with end sleeve: 0.5 mm² to 2.5 mm² |
| Number of channels |
16 |
| Type of contact |
NO contact, 16 A, 3 A |
| Opening width |
< 3 mm |
| Incandescent lamp load |
2000 W |
| Fluorescent lamp load (conventional) parallel-corrected |
1300 W (140 µF) |
| Fluorescent lamp load (conventional) not corrected |
2000 VA |
| Fluorescent lamp load (electronic ballast) |
1200 W |
| Energy saving lamps |
300 W |
| LED lamp < 2 W |
55 W |
| LED lamp 2-8 W |
180 W |
| LED lamp > 8 W |
200 W |
| Inrush current |
max. 800 A / 200 µs |
| Voltage output |
240 V AC |
| Switching output |
Potential-free |
| Switching of various phases |
Possible |
| Suitable for SELV |
Yes if all channels switch at SELV |
| Ambient temperature |
-5 °C … +45 °C |
| Type of protection |
IP 20 |
| Protection class |
II according to EN 60 669 |
